ORBEA MONOCOQUE CARBON
We use the most technologically advanced carbon construction available to make the most sophisticated frame possible – A complex and painstaking process with results you will appreciate in the saddle.
ORBEA ROAD RACING GEOMETRY
Orca Racing Geometry is born from almost 100 years of designing road racing bikes and is the perfect balance of responsiveness and stability. The position is aggressive to maximize body aerodynamics and efficiency. Handling is precise and intuitive. Angles and dimensions are considered carefully across a range of sizes to put more power to the road with every pedal stroke, and more power means more speed.
How can ergonomics help you ride further? Unlike a racing position that is focused on aerodynamics, an endurance position results in a bike that is easier to ride and increases stamina. A shorter cockpit and higher handlebar maximize rider comfort – and more comfort means longer and faster rides.
|Orbea Orca carbon OMR Disc, monocoque construction, HS 1,5″, BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing, EC/DC compatible
|Orbea carbon fork 2021, aluminum steerer, 1-1/8″ head tube
|Acros Alloy 1-1/2″ Internal Cable Routing
|Shimano 105 R7000 34x50t
|Shimano 105 R7000
|Shimano 105 R7000 GS
|Shimano 105 R7000 11-30t 11-Speed
|Shimano R7070 Hydraulic Disc
|Alloy, Tubeless, 700c, 19c, 28H
|Front Wheel Axle
|Orbea Thru Axle 12x100mm M12x2 P1 Solid
|Rear Wheel Axle
|Orbea Thru Axle 12x142mm M12x2 P1 Solid
|Vittoria Zafiro V Rigid bead 700x28c
|OC Road Performance RP21, -6º
|OC RP30-R Road Performance Riser, Reach 70, Drop 125, Rise 15, Flare 5º
|Carbon, 27.2mm, Setback 20
|Fizik Aliante R5
